Hannoband®-BG1

The top tape among the joint sealing tapes

Hannoband®-BG1

Product description

If you want to have perfectly sealed construction joints in the long term, choose Hannoband®-BG1: Even after an outdoor weathering test over more than 15 years in the joint, Hannoband® still clearly exceeds the requirements for driving rain tightness, airtightness and weather resistance of DIN 18542.

^{Hannoband®-BG1} XL
^{Hannoband®-BG1} is also available as ^{Hannoband®-BG1} XL in longer roll lengths especially for window construction. This helps to avoid waste and facilitates quick installation.

^{Hannoband®-BG1-M}
^{Hannoband®-BG1-M} Hanno membrane technology is used for the particularly demanding larger joint widthn.

Tender texts

Properties

for highly stressed primary and cross joints
all relevant test certificates
Resistant to long-term weathering
European Technical Approval ETA 06/0083
complies with DIN 18542:2009, stress group 1
Building material class B1 DIN 4102
Thermal conductivity λ=0.0412 W/mK
driving rain tight ≥ 600 Pa
Joint sound insulation value_RS,W ≥ 60 dB (with double installation)
Temperature resistance from -30°C to +100°C, short-term up to +130°C
open to diffusion
Compatible with paint

Test certificates

MPA Bau Hannover - Materials Testing Institute for the Building Industry Hannover

Testing according to DIN 18542:2009, stress group 1
External monitoring contract
Determination of thermal conductivity

MPA-Hannover - Materials Testing Institute for Materials and Production Technology

Assessment after practical outdoor weathering over a period of 15 years

European Organisation for Technical Approvals

European Technical Approval ETA 06/0083 (CE certificate)

ift Rosenheim

Proof of joint sound insulation

Kiwa N.V., NL-2280 AB Rijswijk

Komo product certificate

Socotec

Certification according to NFP85-570 and NFP85-571

Eurofins Product Testing A/S

Measurement of emissions

GEV - Association of Emission Controlled Installation Materials

Certification with EMICODE® EC1PLUS

eco-bau

Certification "basis"

DIBT - German Institute for Building Technology, Berlin

General building authority approval
Building material class B1 according to DIN 4102

ATI, Architectural Testing, Inc., York, Pennsylvania

Hurricane test according to Miami Dade in accordance with ASTM E284, 330, 331

Installation instructions Hannoband®-BG1

Complicated instructions are a thing of the past, our short video tutorial clearly and comprehensibly shows the correct application steps for the product.
